SKU

VCON3452AT

EAN/GTIN

5412810319930

Height

24 mm

Length

101 mm

Width

101 mm

Weight

296 g

Aspect ratio

16:9

Audio / video / data connections input

SCART Female

Audio / video / data connections output

1x 3.5 mm sound out, 1x Digital Audio, 1x HDMI™ Output

Clock frequency

300MHz

Colour

Grey

Colour formats

24 bit, 36 bit, Deep Color 30 bit

Connection output

HDMI™ Output, 1x Digital Audio, 1x 3.5 mm sound out

Controlling method

Push Button

Data transfer direction

1-way

Device power input connection(s)

DC 5.5 x 7.0 mm

Device type

HDMI™ Converter, HDMI™ Converter

HDMI™ video colour formats

24 bit, Deep Color 30 bit, 36 bit

Input current

1.0A

Input voltage

5 V DC

Material

Aluminium

Maximum bandwith

1.65Gbps

Maximum resolution

1080p

Number of Products in Package

1pcs

Power adapter cable length

1.40m

Power consumption in operating mode

5W

Power consumption in standby mode

2W

Power plug

Euro / Type-C (CEE 7/16)

Power source type

Mains Powered

Resolution standard

Full HD

SmartLife

No

Supported resolutions

1080p@60Hz, 1080i@60Hz, 720p@60Hz, 576p@60Hz, 576i@60Hz, 480p@60Hz, 480i@60Hz

Supported technology

SECAM, Full HD, HDCP, NTSC, PAL
